INTRODUCTION |
PARAMETERS |
| Item | Unit | Parameter |
|---|---|---|
| Max. load capacity | t | 70 |
| Telescopic boom | m | 45 |
| Number of axles | - | 2 |
| Max. hoist height | m | 57.9 |
| Max. load moment | kN.m | 2028.6 |
| Drive engine model | - | QSB6.7-C260-30 SC9DK260.1G3 |
| Drive engine power | kw | 194 192 |
| Drive/Steering | - | 4×4×4 |
| Driving speed | km/h | 40 |
| Dead Weight in Travel State | kg | 44055 46755 |
| Dimensions | mm | 14354×3290×3750 |
| Emission standard | - | Stage IIIA |
