Product Attributes |
Model No.: XN500
Origin: Liaocheng, Shandong, China
Certification: CE ISO
Applicable Industry: Hotels, Farms, Garment Shops, Restaurant, Building Material Shops, Home Use, Retail, Food Shop, Machinery Repair Shops, Manufacturing Plant, Construction Works, Food &Amp; Beverage Factory, Energy &Amp; Mining, Food &Amp; Beverage Shops, Advertising Company, Printing Shops
Status: New
Place Of Origin: China
Types Of: Front Loader
Exercise: Crawler Loader
Warranty Period: 1 Year
Mechanical Test Report: Provided
Video Factory Inspection: Provided
Marketing Type: Other
Core Component Warranty Period: 1 Year
Core Components: Pressure Vessel, Bearing, Pump, Gearbox, Engine, Motor
Machine Weight: 325kg
Max. Load Weight: 500kg
Dump Capacity: 0.22m³
Engine Model: DH270
Rate Power: 5.8kw/3600r/min
Speed: 2.5-4.9km/h
Pressure / Flow: 16Mpa / 36L/min
Tank Of Hydraulic Oil /fuel: 9.1 /6 L
Track Size: 1120x180x275mm
Wheel Base: 910mm
Packaging & Delivery |
| Selling Units | Bag/Bags |
| Package Type | Steel frame |
Advantages of Mini Dumper: |
Specification |
| Machine weight: | 325 kg |
| Maximum load: | 500kg |
| Dump capacity: | 0.22m |
| Engine | Model | DH270 |
| Displacement | 0.270L | |
| Rated power/speed | 5.8Kw/3600r/min | |
| Max. torque | 16.5N.m/2500r/min | |
| Weight | 25kg | |
| Size | 460X 400X450/mm | |
| Speed | Max.speed | 4.9km/h |
| Min. speed | 2.5km/h | |
| Max. gradeability | 30 | |
| Track | Ground pressure | 15.04KPa |
| Material | Rubber | |
| Tightening type | Screw adjustment | |
| Hydraulic system | Pump type | Gear Duplex Pump |
| Pressure | 16MPa | |
| Flow | 36L/min | |
| Hydraulic oil tank | 9.1L | |
| Fuel tank | 6.0L |
| Roller wheel base | 600mm |
| Wheel base | 910mm |
| Track length | 120mm |
| Track height | 275mm |
| Dump front end height | 665mm |
| Platform ground clearance | 380mm |
| Armrest height | 840mm |
| Console height | 970mm |
| Overall width | 710mm |
| Track width | 180mm |
| Dump back end width | 650mm |
| Dump front end width | 440mm |
| Armrests spacing | 600mm |
