Product Attributes |
Model No.: XN 800
Origin: China
Old And New: New
Gearbox Type: Automatic
Emission Standards: Euro 5
Model: XN800
Machine Weight: 630kg
Load Weitght: 800kg
Engine: koop192
Packaging & Delivery |
| Selling Units | units |
| Package Type | Wooden packing |
Specification |
| Machine weight | 920kg | |
| Maximum load | 800kg | |
| Dump capacity | 0.26m³ | |
| Type | Self loading and unloading | |
| Engine | Model | Kubota D722 |
| Displace | 0.719L | |
| Rated power/speed | 10.2 Kw/2500r/min | |
| Max. Torque | 42.9N.m/2000r/min | |
| Weight | 63.1kg | |
| Size | 426×389×520/mm | |
| Speed | Max. speed | 4km/h |
| Min. speed | 2km/h | |
| Max. gradeability | 30° | |
| Track | Ground pressure | 26.13KPa |
| Material | Rubber | |
| Tightening type | Screw adjustment | |
| Hydraulic system | Pump type | Duplex Gear Pump |
| Pressure | 16MPa | |
| Flow | 30L/min | |
| Hydraulic oil tank | 14 L | |
| Fuel tank | 16L | |
| Roller wheel base | 914 mm | |
| Track length | 1230 mm | |
| Length | 1795mm | |
| Track height | 320mm | |
| Height of tip front end from ground | 810mm | |
| Height from self loading bucket to ground | 1690mm | |
| Platform ground clearance | 355mm | |
| Console height | 1005mm | |
| Height of tip back from ground | 1060mm | |
| overall width | 820mm | |
| Track width | 180mm | |
| Tipping bucket width | 620mm | |
| Max. dumping height | 1700mm | |
| Max. Unloading dump height | 2980mm | |
